About Product
- Powerful Cool System
- Quite Operation
- Aerodynamic Technology
- DUAL BARRIER COATING
- MICROPARTICLE CATCHING FILTER(OPTIONAL)
- LONG AIR FLOW
Technical Description
|
Indoor Unit |
MSY-GR13VF-DA1 |
|
Capacity (Tr) |
1 Tr |
|
Star Rating - As Per BEE |
5 Star bee rating |
|
Power Supply |
230 V / 50 Hz / Single Phase |
|
Capacity (Rated* Min-Max) |
3.7(1.4-4.1)kW |
|
Total Input (Rated Min-Max) |
1.01(0.32-1.31)kW |
|
ISEER |
5.02 |
|
Operating Current Rated(Amps) |
4.8 |
|
Air Volume (CFM) Indoor Unit(Low-Mid-Hi-SHi) |
152/187/254/335/445 |
|
SPL Indoor Unit(Low-Mid-Hi-SHi) dB(A) |
19/24/31/38/43 |
|
Refrigerant |
R32 |
Extra Information
|
Indoor unit |
|
|
Dimensions (H x W x D) |
280x838x229 mm |
|
Weight |
10 kg |
|
Outdoor unit |
|
|
Dimensions (H x W x D) |
538x699x249 mm |
|
Weight |
24.5 kg |
|
Ext.Piping |
|
|
Diameter Liquid |
6.35(1/4) mm (inches) |
|
Diameter Gas |
9.52(3/8) mm (inches) |
|
Max.Length Out-In |
20 m |
|
Max.Height Out-In |
12 m |
|
Country of Origin |
India |
