About this Product
- TROPICAL INVERTER TECHNOLOGY
- FAST COOLING
- LONG AIRFLOW/AUTO VANE CONTROL UP AND DOWN/LEFT AND RIGHT
- DUAL BARRIER COATING
- MICROPARTICLE CATCHING FILTER(Standard) AND HIGH DENSITY
- QUIET OPERATION
Technical Description
| Type (Cooling) | Split Air Conditioner (Inverter) |
|---|---|
| Indoor Unit Model | MSY-GR13VFT-DA1 |
| Outdoor Unit Model | MUY-GR13VFT-DA1 |
| Performance Parameters | |
| Capacity (Tr) | 1 Tr |
| Star Rating - As Per BEE | 5 Star |
| Power Supply | 230 V / 50 Hz / Single Phase |
| Capacity (Rated Min-Max) | 3.7 (1.4-4.1) kW |
| Total Input (Rated Min-Max) | 1.01 (0.32-1.31) kW |
| ISEER | 5.02 |
| Operating Current (A) | 4.8 |
| Air Volume (CFM) Indoor Unit (Silent-Low-Mid-Hi-SHi) | 152/187/254/335/448 |
| Compressor, Refrigerant & Ambient Operations | |
| Sound Level (SPL) Indoor Unit (Silent-Low-Mid-Hi-SHi) | 19/24/31/38/43 dB(A) |
| Refrigerant | R32 |
| Dimensions & Weight | |
| Indoor Unit Dimensions (H x W x D) | 280 x 838 x 229 mm |
| Indoor Unit Weight | 10 kg |
| Outdoor Unit Dimensions (H x W x D) | 538 x 699 x 249 mm |
| Outdoor Unit Weight | 24.5 kg |
| External Piping | |
| Diameter Liquid | 6.35 mm (1/4 inches) |
| Diameter Gas | 9.52 mm (3/8 inches) |
| Max. Length Out-In | 20 m |
| Max. Height Out-In | 12 m |
Extra Information
| Manufacturer | MITSUBISHI ELECTRIC INDIA PVT. LTD. |
|---|---|
| Country of Origin | India |
| Item Weight | 35 kg |
| Product Dimensions | 538 x 699 x 249 (MM) |
| Net Quantity | 1 Count |
| Included Components | 1 Indoor Unit, 1 Outdoor Unit, 1 Remote Control, User manual, Warranty Card & 3m Copper wire/ Interconnecting pipe |
| Generic Name | SPLIT AIR - CONDITIONER |
Refund / Returns
This product is not eligible for Return/Refund, Subject to Product Damage
What is in the Box ?
1 Indoor Unit, 1 Outdoor Unit, 1 Remote Control, User manual, Warranty Card 3m Copper wire/ Interconnecting pipe
